BAUDOUIN POWERED SERIES 50HZ
Home /

BAUDOUIN POWERD SERIES

/

BAUDOUIN POWERED SERIES 50HZ

BAUDOUIN POWERED SERIES 50HZ
BAUDOUIN POWERED SERIES 50HZ
BAUDOUIN POWERED SERIES 50HZ
BAUDOUIN POWERED SERIES 50HZ
BAUDOUIN POWERED SERIES 50HZ

BAUDOUIN POWERED SERIES 50HZ

(21KVA—— 4125KVA)

Bodouin is an engine manufacturer, founded in 1903, for more than 100 years, Bodouin has been the main supplier of military diesel engines to the French military, with a complete solution of marine powertrain system, at the end of 2008 officially became a wholly-owned subsidiary of Weichai Group, and in 2010 Bodouin products were originally imported to China. At present, Weichai Bodouin products are produced in France and imported to China for sale, becoming an important level of Weichai marine products.



Inquire Now



Powered by Baudouin Series specification
Genset Model 50HZ 400/230V Open Type Silent Type
ESP PRP Engine Model Size(L*W*H) Size(L*W*H)
KVA KW KVA KW mm mm
IG21B 21  17  19  15 4M06G20/5 1500*750*1050 2188*900*1280 inquiry
IG25B 25  20  23  18 4M06G25/5 1500*750*1050 2188*900*1280 inquiry
IG36B 36  29  33  26 4M06G35/5 1500*750*1050 2188*900*1280 inquiry
IG44B 44  35  40  32 4M06G44/5 1500*750*1050 2188*900*1280 inquiry
IG50B 50  40  45  36 4M06G50/5 1850*800*1100 2288*950*1280 inquiry
IG55B 55  44  50  40 4M06G55/5 1850*800*1100 2288*950*1280 inquiry
IG72B 72  57  65  52 4M10G70/5 1900*870*1180 2688*1080*1450 inquiry
IG88B 88  70  80  64 4M10G88/5 1900*870*1180 2688*1080*1450 inquiry
IG110B 110  88  100  80 4M10G110/5 2050*880*1230 2938*1080*1690 inquiry
IG149B 149  119  135  108 6M11G150/5 2400*950*1510 3288*1130*1850 inquiry
IG165B 165  132  150  120 6M11G165/5 2400*950*1510 3288*1130*1850 inquiry
IG220B 220  176  200  160 6M16G220/5 2850*1040*1580 3958*1280*2150 inquiry
IG253B 253  202  230  184 6M16G250/5 2850*1040*1580 3958*1280*2150 inquiry
IG275B 275  220  250  200 6M16G275/5 2850*1050*1620 3958*1280*2150 inquiry
IG352B 352  282  320  256 6M16G350/5 3050*1100*1800 4188*1400*2220 inquiry
IG385B 385  308  350  280 6M21G400/5 3350*1150*1800 4188*1400*2220 inquiry
IG440B 440  352  400  320 6M21G440/5 3350*1150*1800 4588*1600*2500 inquiry
IG495B 495  396  450  360 6M21G500/5 3350*1150*1800 4588*1600*2500 inquiry
IG550B 550  440  500  400 6M21G550/5 3350*1150*1800 4588*1600*2500 inquiry
IG660B 660  528  600  480 6M33G660/5 3800*1600*2200 5280*2100*2500 inquiry
IG715B 715  572  650  520 6M33G715/5 3800*1600*2200 5280*2100*2500 inquiry
IG748B 748  598  680  544 6M33G750/5 3800*1600*2200 5680*2100*2500 inquiry
IG825B 825  660  750  600 6M33G825/5 3800*1600*2200 5680*2100*2500 inquiry
IG897B 897  717  815  652 8M33G900/5 4000*2000*2250 S20CS/S20C inquiry
IG990B 990  792  900  720 8M33G1000/5 4000*2000*2250 S20CS/S20C inquiry
IG1122B 1122  898  1020  816 8M33G1100/5 4400*2000*2250 S20CS/S20C inquiry
IG897B 897  717  815  652 12M26G900/5 4000*2000*2250 S20CS/S20C inquiry
IG990B 990  792  900  720 12M26G1000/5 4000*2000*2250 S20CS/S20C inquiry
IG1122B 1122  898  1020  816 12M26G1100/5 4400*2000*2250 S20CS/S20C inquiry
IG1265B 1265  1012  1150  920 12M33G1250/5 4700*2200*2400 40HQ inquiry
IG1375B 1375  1100  1250  1000 12M33G1400/5 4700*2200*2400 40HQ inquiry
IG1513B 1513  1210  1375  1100 12M33G1500/5 4700*2200*2400 40HQ inquiry
IG1650B 1650  1320  1500  1200 12M33G1650/5 4700*2200*2400 40HQ inquiry
IG1650B 1650  1320  1500  1200 16M33G1700/5 5400*2250*2500 40HQ inquiry
IG1925B 1925  1540  1750  1400 16M33G1900/5 5400*2250*2500 40HQ inquiry
IG2063B 2063  1650  1875  1500 16M33G2000/5 5400*2250*2500 40HQ inquiry
IG2200B 2200  1760  2000  1600 16M33G2250/5 5400*2250*2500 40HQX inquiry
IG2200B 2200  1760  2000  1600 20M33G2250/5 5400*2250*2500 40HQX inquiry
IG2475B 2475  1980  2250  1800 20M33G2500/5 5800*2800*3400 40HQX inquiry
IG2475B 2475  1980  2250  1800 12M55G2550/5 5800*2800*3400 40HQX inquiry
IG2750B 2750  2200  2500  2000 12M55G2750/5 6200*2850*3290 40HQX inquiry
IG3025B 3025  2420  2750  2200 12M55G3000/5 6500*2850*3290 40HQX inquiry
IG3025B 3025  2420  2750  2200 16M55G3000/5 6500*2850*3290 40HQX inquiry
IG3300B 3300  2640  3000  2400 16M55G3300/5 6500*2850*3290 40HQX inquiry
IG3575B 3575  2860  3250  2600 16M55G3750/5 6500*2850*3290 40HQX inquiry
IG4125B 4125  3300  3750  3000 16M55G4000/5 6500*2850*3290 40HQX inquiry
